LG-MP1000

LG-MP1000 multi-parameter water quality online analysis system is an analytical instrument specially designed for drinking water quality monitoring. The monitoring project covers turbidity, pH, water temperature, residual gas, chlorine dioxide, total chlorine, conductivity, color and other core indicators of water quality safety, and can also access data such as flow and pressure to meet the needs of users.Requirements for different scenarios. Built-in advanced data algorithms can help users accurately control water quality data and ensure water quality safety.

  • High-quality instrument, stable and reliable operation
  • It can realize the centralized collection and display of data on multiple parameters such as pH, turbidity, and residual chlorine.
  • No reagents are required for monitoring, no waste liquid discharge, water saving and environmental protection
  • Automatic recovery after water shutdown, automatic transmission of data after power failure

Detection index: pH, temperature, turbidity, residual chlorine/chlorine dioxide/total chlorine, optional conductivity, ORP, chromaticity, TOC, etc.
Detection principle: pH/temperature/ residual chlorine/Chlorine dioxide/total chlorine/ Conductivity/0RP: Electrochemical method Turbidity: 90° Scattering method: Chromaticity/TOC: Spectroscopy
Range and accuracy: pH: 0-14pH;+0.02pH/Turbidity: 0-40NTU;±2% /Residual chlorine/chlorine dioxide/total chlorine: 0-2/5mg/L;±1%-±5% /Temperature: 0-50℃;±0.5℃℃ / Conductivity: 0-2000µs/cm; ±2% / ORP: -2000mV-+2000mV; +20mV / Color: 0-500 degrees, ±5% or +5 degrees / TOC: 0-20mg /L, ±2% F. S.
System display: 10-inch TFT touch screen, resolution 1024*600, Chinese menu display
Communication method: Output: ModbuS RTU/TCP, support optional wireless communication input: support 4-20mA, RS485
Power requirements: 220VAC 50HZ, support optional 24VDC power supply
Dimensions: 460mm (width)*770mm (height)*250mm (thickness)
